Orange Semiconductor optimizes product performance through innovative technologies. Products are used in welding equipment, photovoltaic new energy, industrial power, industrial motor and other fields.
| High Voltage MOSFETS | MPN | BVDSS (V) | ID (A) | Vgs (V) | RDS(ON) (Ω) Typ | Qg (nC) | Qgs (nC) | Package |
| 1000 | 3 | ±30 | 5.2 | 12 | 2.8 | TO-252,TO-220,TO-220F,TO-263,TO-247,TO-3PF | ||
| 1000 | 5 | ±30 | 3.5 | 42 | 7.3 | TO-252,TO-220,TO-220F,TO-263,TO-3PF | ||
| 1000 | 6 | ±30 | 2.6 | 14.7 | 4 | TO-220,TO-220F,TO-263,TO-247,TO-3PF | ||
| 1000 | 8 | ±30 | 1.8 | 14 | 2 | TO-252,TO-220,TO-220F,TO-263,TO-247,TO-3PF | ||
| 1000 | 10 | ±30 | 1.38 | 43 | 15 | TO-3PB,TO-247,TO-220,TO-220F,TO-3PF | ||
| 1000 | 12 | ±30 | 1.18 | 43 | 15 | TO-263,TO-247,TO-220,TO-220F,TO-3PF | ||
| 1000 | 15 | ±30 | 0.9 | 66 | 13 | TO-247,TO-220,TO-220F,TO-3PF | ||
| 1000 | 18 | ±30 | 0.55 | 66.6 | 15.6 | TO-247 | ||
| 1000 | 30 | ±30 | 0.28 | 185 | 47 | TO-247 | ||
| 1200 | 6 | ±30 | 5.5 | 85 | 14 | TO-247,TO-220,TO-220F,TO-263 | ||
| 1200 | 8 | ±30 | 2.3 | 89.3 | 15.8 | TO-247,TO-220,TO-220F,TO-263 | ||
| 1200 | 10 | ±30 | 2 | 39 | 6 | TO-220,TO-263 | ||
| 1200 | 12 | ±30 | 1.1 | 85 | 14 | TO-247,TO-247Plus | ||
| 1200 | 15 | ±30 | 0.68 | 111 | 18.5 | TO-247,TO-247Plus | ||
| 1500 | 4 | ±30 | 6.3 | 37 | 6 | TO-3PF,TO-3PB,TO-247,TO-220F | ||
| 1500 | 9 | ±30 | 2.2 | 85 | 14 | TO-247 | ||
| 1500 | 12 | ±30 | 1.5 | - | - | TO-247,TO-247Plus | ||
| OR15N150XX | 1500 | 15 | ±30 | 1 | - | - | TO-247,TO-247Plus |
